Customized Machinery
Automatic liquid filling machine
PPD-ALF
Automatic liquid filling machine is designed for different type of liquid to fill into the container,bottle,tank,include different food sauce,chemical liquid for medical liquid,shampoo,bath gel etc.Automatic filling machine adopts piston quantification, integrates electromechanical and pneumatic functions, and electric and pneumatic components are selected by well-known brands, controlled by touch screen and PLC. The design is reasonable, the structure is compact, the appearance is beautiful, the performance is stable and reliable, and the filling accuracy is high. , adaptability, simple operation, easy maintenance and so on.
Features:
1. Automatic filling machine adopts well-known brands of electrical and pneumatic components, low failure rate, stable and reliable performance, long service life;
2. It is made of 316 stainless steel in contact with the materials. It is easy to dismantle, easy to clean, and meets the food hygiene requirements;
3. Filling volume and filling speed adjustment is simple, with no bottle filling function, liquid level automatic control feeding;
4.No need to replace parts, you can quickly adjust the replacement of different shapes and sizes of the bottle, strong applicability;
5.Filling mouth with anti-drip device to ensure no wire drawing, no leakage.
Technical Parameters:
Number of filling : 8
Filling volume: 30-300ml
Applicable bottle height :10-250mm
Applicable bottle diameter :20-150mm
Production capacity: 0-45 bottles/minute
Filling accuracy: ≤±1
Degree of automation :Fully automatic
Power 370W
Weight 450Kg
Dimensions 3000*1000*1850mm
