Four Side Sealing & Packaging Machine
Oral Dissolution Film Boxing Machine
PPD-ODFBM
Oral dissolving film boxing machine is a machine used to automatically pack oral dissolving film into paper boxes, achieving automatic packaging.It is an indispensable part of the packaging production line.This machine is controlled by PLC program and equipped with a touch screen for easy operation and stable operation.
Machine process:
Put the product on the synchronous belt, put the paper box into the feeding port, and when the photoelectric sensor detects the product passing through, the machine automatically drives the box unloading, opening, forming, and pushing the product into the paper box. Then packaging, folding, tongue insertion and forming.
Main Data:
Model：PPD-ODFBM
Paper quality requirement：300 g/m² ≤ Most suitable paper: 350 g/m² ≤450 g/m²
Box Requirements：Box indentation of at least 0.4mm, with pre-folding effect
Box size：60*100*25mm (L*W*H)
Speed：40-50boxes/min
Voltage：220V/50Hz
Power：1.5kw
